- Enhanced locking retention
- Designed for metro fiber networks
- Suitable for 5G transport projects
- Transparent inspection body
- Crush and impact resistant
- IP68 environmental protection
Construction | Description |
Tube To Connector | HDPEMicroduct( DB | DI | TW ) |
| Fluid | Air with blowing system |
| Working Pressure | 20 bar |
| Burst Pressure | 25 bar |
| Estimated Life | 25 years |
| Protection Class | IP68 |
| Water Ingress Test | 0.5 bar during 168 hours |
| Installation Temperature | -15°C to +45°C |
| Operation Temperature | -15°C to +45°C |
| Transport and Storage Temperature | -15°C to +45°C |
| Insertion Force | Size≤12mm,≤ 50 N | Size≥14mm,≤ 120 N |
| Impact Resistance | 1.5J |
| According To Standards | CEI EN 50411-2-8,EN 50411-2-5,EN61300,EN61753-1,EN60068-2-10,EN60794-1-2:2003 |
Construction |
EN 60529:IP68 |
| EN 61300-2-26: Salt Mist |
| EN 61300-2-33: Re-entries |
| EN 61300-2-10: Crush Resistance |
| EN 61300-3-1: Visual Appearance |
EN 61300-2-4: Microduct Retention |
| EN 61300- 2-34: Chemical Resistance |
| EN 50411-2-8:Annex E:Insertion Force |
| EN 61386-22: Glow Wire Test at 750°C |
| EN 60794- 1-2: 2003,Method E4:lmpact |
| EN 50411-2-8:Annex D:Installation Test |
| EN 61300-2-22: Change of Temperature |
| EN60794-1-2 Method E1. Tensile Strength |
EN 61300-2-38: 2006,Method B:Pressure Loss |
| EN 50411-2-8:Annex C: High Pressure Resistance |
| EN 61300-2-23: 1997,Method 2:Water Immersion |
| EN 61386- 24: Conduit Systems Buried Underground |
| EN 61300-2-38:2006, Method A:Sealing Performance |
HDPE Microduct( DB | DI | TW )
Compatible with HDPE microducts for direct-buried, duct-installed and through-wall applications.
Air with blowing system
Designed for air-assisted fiber blowing installation.
20 bar
Supports operation in pressurized microduct networks up to the specified working pressure.
25 bar
Provides a higher pressure limit than the specified working pressure.
25 years
Designed for long-term service in fiber infrastructure applications.
IP68
Provides sealed protection against dust and water ingress for demanding underground applications.
0.5 bar during 168 hours
Validated against water ingress under the stated test condition.
-15°C to +45°C
Supports field installation across a broad temperature range.
-15°C to +45°C
Suitable for continuous operation within the specified temperature range.
-15°C to +45°C
Suitable for transport and storage within the specified temperature range.
Size≤12mm,≤ 50 N | Size≥14mm,≤ 120 N
Low insertion force helps simplify push-in installation in the field.
1.5J
Provides defined resistance to mechanical impact during installation and service.
CEI EN 50411-2-8,EN 50411-2-5,EN61300,EN61753-1,EN60068-2-10,EN60794-1-2:2003
Supports technical specification and compliance review against the listed standards.
